characteristic High-speed transmission rate 1Mbit/s Isolation voltage between input and output High CMR15KV/us at VCM =1500V (ELM453) Guaranteed performance from 0°C to 70°C -40°C to 85°C operating temperature range Compliant with lead-free and RoHS and halogen-free |
application Line receiver Communication and control. Power transistor isolated driver. Low-speed phototransistor optocoupler. High-speed logic isolation. Simulate signal isolation. |
specification
| Product | Datasheet |
Size(mm) |
t PHL/t PLH (ns) |
Supply Voltage(V) |
CTR( %) |
Viso(Vrms) |
CMR(V/us) |
Io(mA) |
|---|---|---|---|---|---|---|---|---|
| ELM452 | 4.4x4.1x2.0 | 800/800 | 30 max | 20-50 | 3750 | 5000 | 16 max | |
| ELM453 | 4.4x4.1x2.0 | 800/800 | 30 max | 20-50 | 3750 | 15000 | 16 max | |
| ELM600 | 4.4x4.1x2.0 | 100/100 | 7 max | - | 3750 | 0 | 50 max | |
| ELM601 | 4.4x4.1x2.0 | 100/100 | 7 max | - | 3750 | 5000 | 50 max | |
| ELM611 | 4.4x4.1x2.0 | 100/100 | 7 max | - | 3750 | 20000 | 50 max | |
| ELM453L | 4.4x4.1x2.0 | 300/650 | 30 max | 20-50 | 3750 | 15000 | 50 max |
download: ELM452
