characteristic Popular T-1 3/4 round package High efficiency Available on tape and reel Reliable and robust UV resistant epoxy The product itself will remain within RoHS compliant version. Compliance with EU REACH Compliance Halogen free. (Br<900 ppm Cl<900 ppm Br+Cl<1500 ppm) |
application Color Graphic Signs Message boards Variable message signs (VMS) Commercial outdoor advertising |
specification
| Product | Datasheet | Size(mm) | λd (nm) (Min./Typ./Max.) | Iv (mcd) (Min./Typ./Max.) | VF (V) (Min./Typ./Max.) | IF (mA) | Viewing Angle |
|---|---|---|---|---|---|---|---|
| 7383/Y7C3-ARUB/MS | 5.8 x 5 x 8.65 | 586~594 | 4500~11250 | 1.8~2.6 | 20 | 30 | |
| 7383/G1C3-ATVA/MS | 5.8 x 5 x 8.65 | 525~535 | 7150~14250 | 2.8~3.6 | 20 | 30 | |
| 7383/BAC3-ANQA/MS | 5.8 x 5 x 8.65 | 465~475 | 2250~4500 | 2.8~3.6 | 20 | 30 | |
|
7383/V7C3-ARTA/MS |
5.8 x 5 x 8.65 | 498~513 | 4500~9000 | 2.8~3.6 | 20 | 30 | |
| 7343/R5C2-ASUB/MS | 5.8 x 5 x 8.65 | 620~628 | 5650~11250 | 1.8~2.6 | 20 | 23 | |
| 7343/Y5C2-ASVB/MS | 5.8 x 5 x 8.65 | 586~594 | 5650~14250 | 1.8~2.6 | 20 | 23 | |
| 7344/V7C2-ASVA/MS | 5.8 x 5 x 8.65 | 498~513 | 5650~14250 | 2.8~3.6 | 20 | 23 | |
| 7343/G1C2-AUWA/MS | 5.8 x 5 x 8.65 | 525~535 | 9000~18000 | 2.8~3.6 | 20 | 23 | |
| 7343/B1C2-APSA/MS | 5.8 x 5 x 8.65 | 465~475 | 2850~7150 | 2.8~3.6 | 20 | 23 |
download: 7383_Y7C3-ARUB_MS
